Large private cinemas
Up to 9,000 ANSI lm provides the light budget for large image areas, lower-gain acoustically transparent materials and more ambitious luminance targets.
Barco · Theater & Media Room · Native CinemaScope
Njord Cinemascope
Njord Cinemascope combines the Njord high-output three-chip DLP platform with a native 2.37:1, 5120 × 2160 imaging engine, making it especially interesting for constant-height CinemaScope rooms.
High-output specialist residential
Light outputUp to 9,000 ANSI lm
Imaging3-chip DLP
Resolution5120 × 2160 · 2.37:1
OpticsTLD+ interchangeable lenses
WHY IT EXISTS
A high-output Barco platform built around CinemaScope from the imaging device outward.
Njord Cinemascope retains the scale, output and TLD+ installation flexibility of Njord, but its 5120 × 2160 imaging engine is proportioned around a 2.37:1 frame rather than conventional 16:9.
That makes it especially compelling for constant-height cinemas where scope presentation is the architectural priority and the system should not depend on an external anamorphic lens to create a native wide image.
IDEAL APPLICATION
Where this projector makes sense.
Architecturally difficult throws
The TLD+ ecosystem spans ultra-short to very long throw options, dramatically expanding possible projector positions.
Projection-room installations
At roughly cinema-projector scale, heat, airflow, electrical supply, service clearances and noise isolation deserve proper design.
PROJECTION OPTICS
This is where Barco’s lens ecosystem becomes a major reason to choose the platform.
Njord supports an exceptionally broad TLD+ family, from approximately 0.41:1 90-degree ultra-short throw through long-throw optics beyond 10:1. Exact shift and throw vary with lens and configuration.
Lens ecosystemTLD+ approx. 0.41–10.83:1Use Barco’s current lens calculator for final geometry, shift and safety-distance validation.
KEY SPECIFICATIONS
The numbers to establish first.
BrightnessUp to 9,000 ANSI lm
Imaging architecture3-chip DLP
Resolution5120 × 2160
Aspect ratio2.37:1
Light sourceLaser phosphor
Contrast20,000:1 with DynaBlack · 2,000:1 sequential · 600:1 ANSI
Lens rangeTLD+ approx. 0.41–10.83:1
NoiseApprox. 43 dB(A) at 25°C
Heat outputUp to approx. 5,876 BTU/h
WeightApprox. 48 kg excluding lens
HDRHDR support via Pulse platform
Specifications are based on manufacturer-published information available at launch preparation. Options can vary by firmware, lens, configuration and region. Always verify final project data before ordering.
Manufacturer reference: Barco Njord Cinemascope product information
PROJECT CONTEXT
Available with specialist regional support.
For projects available through our regional specialist channel, we can help with projector selection, optics, screen geometry, processing and integration.
RegionSouthern Africa, with selected projects in Mauritius and Seychelles.
DesignScreen size, optics, projector position, cooling and signal processing considered together.
SupportSpecification, integration and ongoing system requirements are discussed before purchase.
Next stepEmail the room dimensions, screen width and projector position so we can start with the geometry.
PROJECT ENQUIRY
Start your purchasing journey.
Tell us about the room, screen and performance target. We will help establish whether Njord Cinemascope is the right fit and what the complete projection system requires.
